The Hayward Pro Series Sand Filter is a high-performance, corrosion-proof filtration system designed for optimal pool water clarity. This manual provides a comprehensive guide for installation, operation, and maintenance to ensure peak performance and longevity of your pool filtration system.
1.1 Overview of the Hayward Pro Series Sand Filter
The Hayward Pro Series Sand Filter is a high-performance, corrosion-proof filtration system designed for residential and commercial pools. It utilizes high-rate silica sand to capture dirt and debris, ensuring crystal-clear water. Known for its durability and superior flow characteristics, this filter is performance-matched with Hayward pumps for optimal efficiency. Its robust design and advanced technology make it a reliable choice for pool owners seeking consistent water quality and long-lasting performance.
1.2 Importance of the Owner’s Manual
The owner’s manual is essential for the proper installation, operation, and maintenance of the Hayward Pro Series Sand Filter. It provides detailed instructions, safety precautions, and troubleshooting tips to ensure optimal performance. By following the manual, users can prevent potential damage, maintain water quality, and extend the lifespan of the filter. It also outlines warranty information and technical specifications, making it a vital resource for both new and experienced pool owners to maximize their system’s efficiency and safety.
Key Features and Benefits
The Hayward Pro Series Sand Filter offers high-performance filtration, a corrosion-proof design, and superior flow characteristics, ensuring clean pool water and long-lasting durability with minimal maintenance.
2.1 High-Performance Filtration
The Hayward Pro Series Sand Filter delivers exceptional water purification, capturing contaminants as small as 20 microns. Its advanced design ensures efficient removal of dirt, dust, and debris, providing crystal-clear pool water; Utilizing high-rate silica sand, the filter maximizes flow rates while maintaining superior filtration performance. This results in cleaner water with minimal energy consumption, making it an ideal choice for pool owners seeking reliable and efficient filtration solutions.
2.2 Corrosion-Proof Design
The Hayward Pro Series Sand Filter features a durable, corrosion-proof construction, ensuring long-lasting performance in harsh pool environments. Its robust design withstands exposure to water, chemicals, and weather conditions, preventing rust and damage. The filter’s high-quality materials and seamless engineering provide reliability and minimize maintenance needs, making it a dependable choice for pool filtration systems.
2.3 Superior Flow Characteristics
The Hayward Pro Series Sand Filter is engineered with superior flow characteristics, ensuring efficient water circulation and optimal filtration performance. Its advanced design maximizes flow rates while minimizing pressure loss, providing clearer pool water with less energy consumption. The filter’s large diameter and smooth internal pathways allow for higher throughput, making it ideal for larger pools and demanding applications. This feature enhances overall system efficiency and contributes to a cleaner, healthier swimming environment.
Safety Precautions
Always follow basic safety guidelines to prevent injury and ensure proper system operation. Secure the strainer cover tightly and avoid electrical shock risks. Use only genuine Hayward parts.
3.1 Basic Safety Guidelines
Always adhere to essential safety practices to prevent injuries and ensure safe operation. Secure the strainer cover tightly to avoid leaks and potential hazards. Avoid electrical risks by following proper grounding and bonding procedures. Never operate the system without ensuring the manual air relief valve is open. Keep loose clothing and long hair tied back when servicing the filter. Use only genuine Hayward replacement parts to maintain safety and performance standards. Ensure the system is properly grounded to prevent electrical shock risks. Follow all instructions carefully to avoid system damage or personal injury. Regularly inspect the filter and its components for wear or damage. Keep children and unauthorized individuals away from the filtration system while it is in operation. Always turn off the pump and disconnect power before performing any maintenance or repairs. Properly vent the filter tank before opening to release any trapped air or pressure. Never attempt to modify or tamper with the filter’s design or components, as this could lead to malfunction or injury. By following these guidelines, you can ensure a safe and efficient filtration system for your pool.
3.2 Electrical Safety Considerations
Ensure proper electrical grounding and bonding of the filter system to prevent shock hazards. Always disconnect power before servicing the filter or performing maintenance. Use only GFCI-protected circuits for pool equipment; Avoid exposing electrical components to water or moisture. Never operate the system with damaged or frayed cords. Keep electrical connections secure and tightened to prevent arcing or short circuits. Follow all local electrical codes and regulations when installing or modifying the system. Regularly inspect electrical components for wear or damage and replace them immediately if necessary. Properly ground the system according to the manufacturer’s instructions to ensure safe operation. Use only Hayward-approved electrical parts to maintain safety and performance standards. Always turn off the power at the circuit breaker before working on the system. Ensure the system is properly vented to avoid trapped air or pressure that could lead to electrical issues. By adhering to these electrical safety guidelines, you can minimize risks and ensure a safe and reliable filtration system for your pool.
3.3 Proper Use of Safety-Alert Symbols
Recognize and understand safety-alert symbols to ensure safe operation. These symbols highlight critical precautions to prevent injury or equipment damage. The warning label indicates potential hazards, while the notice label provides important operational information. Always follow instructions accompanying these symbols. Failure to comply may result in severe injury or death; Familiarize yourself with symbols like the electrical warning and moving parts caution. Refer to the manual for detailed explanations of each symbol to ensure proper usage and safety. Take all necessary precautions seriously;
Installation Instructions
Ensure proper site preparation, leveling, and alignment. Secure the filter to a sturdy base, connect plumbing, and follow manual guidelines for electrical connections and system setup.
4.1 Pre-Installation Requirements
Before installing the Hayward Pro Series Sand Filter, ensure the site is level, well-drained, and accessible. Select a location near the pool to minimize plumbing complexity. Check local building codes and regulations for compliance. Ensure all necessary tools and materials, such as a level, wrench, and filter sand, are available. Read the manual thoroughly to understand the installation process and safety guidelines. Proper preparation ensures a smooth and safe installation experience.
4.2 Step-by-Step Installation Process
- Position the filter on a level, stable surface and secure it using the provided hardware.
- Connect the inlet and outlet pipes to the pool pump and filter, ensuring proper alignment and sealing.
- Load the filter tank with the recommended amount of No. 20 silica sand, following the manufacturer’s instructions.
- Reattach the strainer cover and tighten the lock ring securely.
- Set the filter control valve to the “Filter” position and ensure all system valves are open.
- Turn on the pump and check for leaks or improper connections.
Follow these steps carefully to complete the installation and ensure proper system operation.
4.3 Securing the Strainer Cover
Securing the strainer cover is essential for proper filter operation. Place the cover onto the pump housing, ensuring it aligns with the lock ring. Tighten the lock ring evenly to create a watertight seal. Avoid over-tightening, as this could damage the cover or housing. Once secured, inspect the area for any signs of leaks. Properly securing the strainer cover prevents contamination and ensures efficient filtration performance throughout the system.
Operating the Filter
Start the system pump and ensure all valves are set to allow water to return to the pool. Use the filter control valve for optimal filtration and backwashing. Monitor performance regularly to maintain clean and clear pool water. Proper operation ensures efficient filtration and extends the lifespan of the system.
5.1 Starting the System Pump
To start the system pump, ensure all valves are set to allow water to flow back into the pool. Open the manual air relief valve fully before starting the pump. Once operational, close the valve when a steady stream of water is visible, ensuring no air is present. Do not adjust the filter control valve during operation. Proper startup ensures efficient filtration and prevents damage. Always follow the manufacturer’s guidelines for optimal performance and longevity.
5.2 Understanding the Filter Control Valve
The Hayward Pro Series Sand Filter features a multi-position filter control valve that directs water flow for different operations. It allows you to switch between filter, backwash, rinse, recirculate, and drain modes. Proper operation involves depressing the handle before turning to prevent seal damage. Always ensure the valve is in the correct position for the desired function. Improper use can lead to reduced efficiency or system damage, so follow manual guidelines for optimal performance and longevity.
5.3 Monitoring System Performance
Regularly monitor the Hayward Pro Series Sand Filter’s performance to ensure optimal water quality. Check the pressure gauge for increases, which indicate the need for backwashing. Observe the filter’s flow rate and clarity of pool water. Listen for unusual noises that may signal issues. Maintain the recommended sand level and inspect the tank for leaks. Proper monitoring ensures efficient filtration, prevents system damage, and keeps your pool water clean and safe for swimming.
Maintenance and Care
Regular maintenance ensures optimal performance of your Hayward Pro Series Sand Filter. Clean the filter media, inspect for leaks, and replace sand as needed to maintain efficiency.
6.1 Regular Cleaning and Inspection
Regular cleaning and inspection are essential for maintaining the Hayward Pro Series Sand Filter’s efficiency. Backwash the filter as needed to remove trapped debris. Inspect the sand media for wear and tear, ensuring it remains level and free of contamination. Check the strainer cover and O-rings for proper sealing to prevent leaks. Additionally, monitor the filter’s pressure gauge; unusual readings may indicate the need for cleaning or maintenance. Regular inspections help prevent clogging and ensure optimal water filtration.
6.2 Replacing Filter Sand
Replace the filter sand every 5 to 7 years or as needed. Turn off the pump and drain the filter tank. Remove the old sand using a shop vacuum or by scooping it out. Inspect the filter tank and laterals for damage. Add new high-rate silica sand (No. 20, 0.45mm ౼ 0.55mm) to the recommended level. Ensure the sand is evenly distributed and the tank is refilled. Check for leaks after refilling and restart the system to test performance.
6.3 Checking for Leaks and Damage
Regularly inspect the filter tank, connections, and valves for signs of leaks or wear. Ensure the strainer cover is securely locked to prevent water loss. Check the O-ring and gaskets for proper sealing. Inspect the laterals and underdrain for blockages or damage. If leaks are detected, tighten connections or replace damaged parts. Always turn off the pump before performing inspections. Address any issues promptly to maintain system efficiency and prevent further damage. Consult a professional if necessary.
Troubleshooting Common Issues
Identify common problems such as leaks, filter valve malfunctions, or pump startup issues. Refer to the manual for solutions, including tightening connections or replacing worn parts.
7.1 Identifying Common Problems
Common issues with the Hayward Pro Series Sand Filter include air leaks, high pressure readings, reduced water flow, and malfunctioning filter valves. Air leaks often occur at connections or the strainer cover, while high pressure may indicate clogged sand or dirty filters. Reduced flow can result from blocked pipes or valve misalignment. Malfunctioning valves may stem from worn gaskets or improper alignment. Regular inspection and maintenance are crucial to prevent and address these issues promptly.
7.2 Solutions for Malfunctioning Parts
For malfunctioning parts, inspect and clean the filter valve and strainer basket regularly. Replace worn gaskets or seals to prevent leaks. If air leaks occur, tighten connections or replace the strainer cover lock ring. For high pressure, backwash the filter or replace clogged sand. Ensure all valves are properly aligned and functioning. Refer to the manual for specific part replacements and always use genuine Hayward parts to maintain optimal performance and warranty validity.
7.3 Resetting the System
To reset the system, ensure the pump is off and all valves are in the correct position. Move the filter control valve to the “backwash” position, then rinse thoroughly. Return the valve to “filter” mode and restart the pump. Allow the system to run for 2-3 minutes to clear any air. Monitor pressure gauges and flow rates to ensure proper operation. If issues persist, refer to the troubleshooting guide or contact Hayward support for assistance.
Technical Specifications
The Hayward Pro Series Sand Filter includes models S144T, S166T, and S210T, with dimensions ranging from 21-24 inches in diameter and weighing up to 50 lbs.
8.1 Filter Media Requirements
The Hayward Pro Series Sand Filter requires high-rate No. 20 silica sand with a size range of 0.45mm to 0.55mm for optimal performance. Using the correct media ensures efficient filtration and prevents damage to the system. Only genuine Hayward replacement parts are recommended to maintain warranty validity and system longevity. Proper sand installation is critical, and the filter tank must be filled to the specified level to ensure even distribution and effective water purification. Always refer to the manual for precise measurements and guidelines.
8.2 Flow Rate and Compatibility
The Hayward Pro Series Sand Filter is designed to deliver optimal flow rates, ensuring efficient water circulation and pool cleaning. It is compatible with a variety of pool pumps and systems, making it a versatile choice for different pool sizes and configurations. The filter’s flow rate is carefully matched to its design, supporting smooth operation and consistent water clarity. Proper sizing and system compatibility are essential for maximizing performance and longevity, as outlined in the technical specifications.
8.3 Dimensions and Weight
The Hayward Pro Series Sand Filter comes in various sizes, with dimensions ranging from 22 to 31 inches in height and 19 to 24 inches in diameter, depending on the model. The weight varies between 45 to 60 pounds, ensuring stability and durability. These dimensions are designed to fit standard pool equipment setups, making installation straightforward. Proper space allocation is recommended for optimal performance and ease of maintenance, as outlined in the technical specifications section of the manual.
Warranty Information
Hayward offers a limited warranty covering defects in materials and workmanship for the Pro Series Sand Filter. The warranty period varies by component, with detailed terms provided in the manual. Proper registration and adherence to maintenance guidelines are required for coverage eligibility.
9.1 Coverage and Duration
The Hayward Pro Series Sand Filter is covered under a limited warranty that protects against defects in materials and workmanship. The warranty period typically lasts for one year from the date of purchase, covering parts and labor. Specific components may have extended coverage, as outlined in the manual. Exclusions include damage caused by misuse, improper installation, or failure to follow maintenance guidelines. Regular maintenance is required to uphold warranty validity. For full details, refer to the warranty section in the manual.
9.2 Exclusions and Limitations
The warranty does not cover damage resulting from misuse, improper installation, or failure to maintain the filter as specified; Exclusions include issues caused by scaling, corrosion from chemical imbalances, or unauthorized modifications. Additionally, damage from extreme weather, pests, or normal wear and tear is not covered. The warranty also excludes third-party parts or labor. For detailed exclusions, refer to the warranty section in the manual to understand coverage boundaries and ensure compliance with all terms and conditions outlined by Hayward.
9.3 Filing a Warranty Claim
To file a warranty claim, contact Hayward Pool Products, Inc., providing proof of purchase and a detailed description of the issue. Ensure the product serial number is included for verification. Claims must be submitted within the warranty period. Unauthorized modifications or improper use may void the warranty. For assistance, contact Hayward support at 908-351-5400 or visit their website for further instructions. Ensure all required documentation is complete to facilitate a prompt resolution.
Additional Resources
For further assistance, visit Hayward’s official website or contact their support team at 908-351-5400. Additional resources include online manuals, troubleshooting guides, and authorized service centers.
10.1 Contacting Hayward Support
For assistance with your Hayward Pro Series Sand Filter, contact Hayward Pool Products, Inc. at 908-351-5400 or visit their official website at www.haywardpool.com.
Their support team is available to address questions, troubleshooting, and parts inquiries.
Additionally, authorized service centers and online resources provide further guidance.
Always refer to the manual or official channels for genuine Hayward parts and support to ensure optimal performance and warranty compliance.
10.2 Online Manuals and Guides
Hayward provides comprehensive online manuals and guides for the Pro Series Sand Filter. Visit their official website at www.haywardpool.com to download PDF versions of the manual, ensuring access to the latest updates and detailed instructions. These resources cover installation, operation, maintenance, and troubleshooting, offering a convenient reference for pool owners. Online guides also include technical specifications and safety precautions, ensuring optimal use of your Hayward Pro Series Sand Filter.
10.3 Authorized Service Centers
For professional assistance, Hayward recommends visiting authorized service centers. These centers offer expert installation, maintenance, and repairs for your Pro Series Sand Filter. Trained technicians ensure compliance with manufacturer guidelines, guaranteeing optimal performance and longevity. Locate the nearest authorized service center through Hayward’s official website or by contacting their customer support team. This ensures genuine parts and reliable service, maintaining your pool filtration system at its best.
The Hayward Pro Series Sand Filter ensures efficient, reliable pool water filtration. By following this manual, you can maintain optimal performance, enjoy clean water, and extend system longevity.
11.1 Summary of Key Points
The Hayward Pro Series Sand Filter is a high-performance, corrosion-proof system designed for optimal pool water clarity. Proper installation, regular maintenance, and adherence to safety guidelines are crucial for longevity. The filter uses high-rate silica sand and features superior flow characteristics. Always follow the manual’s instructions for operations like backwashing and sand replacement. By maintaining the system as recommended, you ensure clean, safe pool water and extend the filter’s lifespan.
11.2 Final Tips for Optimal Performance
For optimal performance, always use high-rate silica sand and follow the manual’s maintenance schedule. Regularly inspect and clean the filter, and replace sand as needed. Ensure the strainer cover is securely locked and check system valves for proper alignment. Monitor the filter’s pressure gauge and backwash when recommended. By adhering to these tips, you’ll maintain clear pool water, extend the filter’s lifespan, and ensure efficient operation.
